Hollyland Pyro H 4K HDMI Wireless Video Transmitter
The Hollyland Pyro H transmitter offers HDMI input and has an extremely low latency of 60 ms allowing line-of-sight transmission up to 396 m away. When using broadcast mode with up to four receivers and two mobile devices, the system supports transmission up to a distance of 600 feet (198 m). The device also has an HDMI loop output for displaying your local feed on a monitor. A USB-C port can power the device and also supports plug-and-play UVC control. The built-in frequency scanner allows you to select the clearest frequency for your transmission.
Hollyland Pyro H 4K HDMI Wireless Video Transmitter
2x Antenna
USB-A to USB-C Adapter
Inputs/Outputs
Antenna I/O | 2x RP-SMA Male |
Video I/O | 1x HDMI 1.4b Input |
HDCP Support | Not Specified by Manufacturer |
Embedded Audio | HDMI |
Audio I/O | No |
Power I/O | 1x Barrel Input |
Encryption | No |
Wireless
Wireless Range | 1300' / 396.2 m (Line-of-Sight) |
Channel Bandwidth | 40MHz, 20MHz |
Frequency Range | 5.15 to 5.25 GHz |
Latency | 60ms |
RF Power | 23 dBm |
RF Sensitivity | -85 dBm |
WiFi | Wi-Fi 4 (802.11n); Dual Band (2.4 & 5 GHz) |
Bluetooth | No |
Mobile App Compatible | Yes: Android & iOS |
Cellular Support | No |
Format Support
Video Format | HDMI |
Wireless Video Compression | Uncompressed |
Timecode Support | Yes |
Power
Input Power | 6 to 16 VDC |
Power Consumption | 7 W |
Mounting
Mounting | 1x 1/4"-20 Female |
Environmental
Environmental Protection | No |
Certifications | No |
General
Dimensions | 4.3 x 2.5 x 1.3" / 109 x 62.3 x 33.4 mm |
Weight | 6.8oz / 192g |
