Aida PTZ-NDI-X12 - Full HD NDI|HX PTZ Camera with 12x Optical Zoom
Op werkdagen voor 17.00 besteld, zelfde dag verzonden! Mits voorradig
Gratis verzending vanaf € 100,-
085 130 5392
Topkwaliteit, slim geprijsd
Meedenkers en Oplossers
Tailored Services
EU verantwoordelijke partij (GPSR):
Mediamachine B.V., Hazepad 41-43, 1544 PW Zaandijk
Mediamachine B.V., Hazepad 41-43, 1544 PW Zaandijk
Description
Key features
- NDI|HX for video and control over the network
- 12x optical zoom (F1.5-F3.0) with a wide 72.5° field of view
- 1/2.5" progressive CMOS sensor, Full HD up to 1080p60
- Simultaneous 3G-SDI, HDMI, USB 3.0 and IP output (NDI|HX, RTSP, RTMP)
- Pan 340° and tilt +90°/-30° with 128 presets
- PoE+ (802.3at) for power, video and control over a single cable
How it works
The camera appears as an NDI source in your production software and can be controlled directly over NDI. It also outputs SDI and HDMI for traditional switchers and USB for video conferencing. Its wide angle suits smaller rooms.
Applications
Meeting rooms, classrooms, houses of worship, smaller venues and studios working with NDI.
Limitations
Full HD, not 4K. NDI|HX is compressed (not Full NDI). Limited zoom for long distances; choose the PTZ-NDI-X20 or PTZ-NDI3-X20 for that. For indoor use.
In de doos
- IR remote control
- Camera mounting bracket
- Power adapter with cable
Technische specificaties
| Sensor | 1/2.5" progressive CMOS |
| Effective pixels | 1920 x 1080 |
| Resolutions | 1080p 60-23.98, 1080i 60/59.94/50, 720p 60-25 |
| Outputs | 3G-SDI, HDMI, USB 3.0/2.0, IP (NDI|HX, RTSP, RTMP) |
| Color space | 4:2:2 YCbCr, 10-bit |
| Minimum illumination | 0,1 lux |
| Zoom | 12x optisch / optical, F1.5-F3.0 |
| Field of view | 72,5° |
| Pan / tilt | Pan 340° (tot / up to 120°/s), tilt +90° / -30° (tot / up to 80°/s) |
| Presets | 128 |
| Audio input | 3,5mm TRS stereo |
| Control | VISCA (RS-232, RJ45), NDI, web UI, IR |
| Power | 12V DC (9-15V) of / or PoE+ (802.3at) |
| Dimensions | 155 x 160 x 170 mm |
| Weight | ca. 1,35 kg |
| Operating temperature | 0-40 °C (binnen / indoor) |
