Dracast Plus Series LED2000 Daylight LED Light Panel
Key Features
- For Film, Broadcast & Video Production
- Output: 8100 Lux at 3.3' (5600K)
- 5600K CCT
- 15 x 24 x 2" Panel; AC/DC Operation
- CRI 95
- Onboard & DMX Control
- 45° Beam Angle
- 0-100% Dimming
- Digital Display & Aluminum Chassis
- Includes Power Adapter
Expanding on their line of panels, the Plus Series LED2000 Daylight LED Light Panel from Dracast adds a digital display for adjusting output as well as 5-pin XLR DMX input and output for linking and has a standard 4-pin XLR DC input for power. The light features 2048 LEDs with a high CRI of 95 for excellent color accuracy. Also, this model has a daylight-balanced color temperature of 5600K for matching with natural light and other fixtures.
The light offers a spot beam angle of 45°, as well as dimming from 0-100%. Benefitting operation, it can run from either a DC source, such as a 28.8V Block battery, or a universal 100-240 VAC adapter. The light is durable as well, with an aluminum chassis, frame, and mounting yoke, and it only consumes 130W of power. Additionally, weighs 9.5 lb and measures 15 x 24 x 2" in size.
Photometrics
10000 lux/929 fc at 3'
3450 lux/321 fc at 6'
1785 lux/166 fc at 9'
1050 lux/98 fc at 12'
| Item Type | 1x LED Light Panel |
| Included Storage Case | No |
| Photometrics | 5600K: 752 fc / 8100 Lux at 3.3' / 1 m* 929 fc / 10,000 Lux at 3' / 0.9 m 321 fc / 3450 Lux at 5.9' / 1.8 m 166 fc / 1785 Lux at 8.9' / 2.7 m 98 fc / 1050 Lux at 11.8' / 3.6 m |
| Color Temperature | 5600K |
| Color Modes | Daylight |
| Color Accuracy Standard | CRI 95 |
| Dimming | Built-In Dimmer (Continuous) • 0 to 100% |
| Front Accessory Mount | Proprietary |
| Power Source | AC to DC Adapter (Included) Battery (Not Included) |
| Battery | 1x Rechargeable (Not Included) |
| Input Power | 24 VDC 110 to 240 VAC, 50 / 60 Hz at 2 A |
| Power Consumption | 130 W |
| Fixture Mounting | 1x 5/8" Receiver (Via Yoke Mount) |
| Item Type | 1x LED Light Panel |
| Included Storage Case | No |
| Photometrics | 5600K: 752 fc / 8100 Lux at 3.3' / 1 m* 929 fc / 10,000 Lux at 3' / 0.9 m 321 fc / 3450 Lux at 5.9' / 1.8 m 166 fc / 1785 Lux at 8.9' / 2.7 m 98 fc / 1050 Lux at 11.8' / 3.6 m *Standardized Measurement Calculated Internally Based on Closest Distance |
| Color Temperature | 5600K |
| Color Modes | Daylight |
| Color Accuracy Standard | CRI 95 |
| Dimming | Built-In Dimmer (Continuous) • 0 to 100% |
| Cooling System | No |
| Expected Lamp Life | 50,000 Hours |
| Beam Angle | 45° |
| Built-In Flash | No |
| Preprogrammed Effects | No |
| Umbrella Mount | No |
| Front Accessory Mount | Proprietary |
| Power Source | AC to DC Adapter (Included) Battery (Not Included) |
| Inputs/Outputs | 1x XLR 4-Pin Power Input (24 VDC) 1x XLR 5-Pin DMX Input 1x XLR 5-Pin DMX Output |
| Battery | 1x Rechargeable (Not Included) |
| Input Power | 24 VDC 110 to 240 VAC, 50 / 60 Hz at 2 A |
| Included Adapter / Cable | 1x USA Type-A/B to XLR 4-Pin AC to DC Adapter |
| Inline Switch | No |
| Power Pass-Thru | No |
| Power Consumption | 130 W |
| Yoke Type | Manually-Operated Yoke (90° Tilt) |
| Fixture Mounting | 1x 5/8" Receiver (Via Yoke Mount) |
| Display | LCD |
| Environmental Resistance | No |
| Certifications | CE , RoHS |
| Materials | Aluminum (Housing) |
| Dimensions | 22 x 13" / 55.88 x 33.02 cm (Fixture Panel) 23.7 x 14.8 x 2.7" / 60.2 x 37.6 x 6.9 cm (Fixture) 26 x 18.6 x 2.7" / 66 x 47.2 x 6.9 cm (Fixture with Yoke) |
| Weight | 9.5 lb / 4.3 kg |
| Package Weight | 15.6 lb |
| Box Dimensions (LxWxH) | 29 x 22 x 5.5" |
