Blackmagic Design StudioBridge 100G

Features

The Blackmagic Design StudioBridge 100G from Blackmagic Design is a professional 1 RU IP video bridge for integrating high-quality SMPTE ST-2110 video streams within modern broadcast infrastructures. The system supports redundant 100G networks and is designed for live productions, remote workflows, and high-end IP-based studio environments.

• 1 RU SMPTE ST-2110 IP video bridge

• Supports one or two IP video streams

• Up to UHD 4K60 support

• Redundant 100GbE QSFP28 connections

• SMPTE 2022-7 redundancy support

• 10-bit 4:2:2 video processing

• Support for Rec.709 and Rec.2020

• 16 embedded audio channels per stream

• Front panel LCD monitoring display

• Integrated audio monitoring via speaker and headphone output

• 2x 10G RJ45 accessory ports

• 2x SFP fiber optic connections

• NMOS network management support

• Redundant power supply via dual IEC connectors

Operation

The StudioBridge 100G converts one or two SMPTE ST-2110 IP video streams into redundant 100GbE outputs for use within professional broadcast networks.

The system supports SMPTE 2022-7, where identical video streams are transmitted over two separate network paths for maximum reliability during live broadcasts.

Thanks to automatic format detection, the device supports various HD and Ultra HD video standards up to 4K60 without manual configuration.

Operators can monitor real-time video, audio, and system information via the built-in LCD screen. Additionally, the integrated speaker and headphone output offer direct audio control during productions.

Application

The Blackmagic Design StudioBridge 100G is suitable for:

• SMPTE ST-2110 broadcast workflows

• Live television productions

• Remote production environments

• IP-based studio infrastructures

• UHD 4K broadcast applications

• Redundant 100G network connections

• Camera integration within IP workflows

• Audio and video monitoring

• High-end live events

Thanks to the compact 1 RU design, the system is easy to integrate into existing racks and mobile production systems.

Limits

• No built-in video mixer or switcher functionality

• Requires SMPTE ST-2110 infrastructure

• No wireless connectivity

• No touchscreen operation

• Primarily intended as an IP video bridge and not as a recorder or converter for consumer workflow

Key features

SMPTE ST-2110 integration

Full support for SMPTE 2110-20, 2110-21, 2110-30, and 2110-40 standards.

Redundant 100G networking

Dual QSFP28 100GbE connections support SMPTE 2022-7 redundancy for maximum reliability.

UHD 4K support

Supports HD and Ultra HD video standards up to 4K60.

Integrated monitoring

Front panel LCD display with real-time video, audio, and system status.

Professional audio support

16 embedded audio channels per stream plus direct monitoring via speaker and headphone output.
