Description

Convert from 12G-SDI to HDMI, Supports all video formats including SD, HD, 6G and 12G-SDI rates and includes down converter when working with Ultra HD as the HDMI monitor will select the best format it can support, De-embed audio to balanced analog or AES/EBU formats and timecode output, Perfect for using HDMI televisions as SDI broadcast monitors and for connecting to video projectors,

Technische specificaties

SDI Video Input

1 x 12G-SDI SD/HD/2K/4K auto switching,
SDI Video Output

1 x 12G-SDI loop output,
HDMI

1 x HDMI 2,0 type A connector with support for 2160p60,
Analog Audio Output

2 channels professional balanced analog audio via XLR connectors, Right XLR can be configured for Timecode output,
AES/EBU Audio Output

4 channels professional 110Ω balanced digital audio via XLR connectors, Right XLR can be configured for Timecode output,
Multi Rate Support

Automatic switching between SD/HD/2K and 4K,
Updates and Configuration

USB or Ethernet,

Re-Clocking
Yes

Blackmagic Design Teranex Mini - SDI to HDMI 12G
