Accsoon CineView M7 7" Touchscreen Recording Monitor

Features

The Accsoon CineView M7 is a professional 7" on-camera monitor with recording function , suitable for 4K workflows via HDMI and HD workflows via 3G-SDI. The screen offers a 1920 × 1080 resolution , 1000 cd/m² brightness , and full 100% Rec. 709 calibration .

Key features:

• 7″ multi-touch LCD

• 1920 × 1080 resolution

• 1000 cd/m² brightness

• 1000:1 contrast ratio

• HDMI 2.0 in/out up to DCI 4K60

• 3G-SDI in/out up to 1080p60

• Internal recording up to 4K60 (HDMI)

• 3D LUT support

• Waveform, vector scope, histogram

• H.264/H.265 recording

The monitor combines monitoring tools with direct recording functionality.

Operation

The edge-lit LED-backlit LCD panel supports a wide 176° viewing angle and is factory calibrated to 100% Rec.709 for consistent color reproduction.

Video signals:

• HDMI 2.0 : up to DCI 4K60

• 3G-SDI : up to 1080p60

Recording is possible via:

• SD card

• USB port (USB stick or external SSD)

Supported recording formats:

• H.264

• H.265

• CBR and VBR bitrate settings

• Recording with or without 3D LUT applied

The integrated SmartOS provides file management, playback and monitoring tools.

Application

The CineView M7 is suitable for:

• On-camera monitoring in film and video production

• External recording via HDMI or SDI

• Live productions and multi-camera setups

• Color control and exposure analysis on set

• Gimbal and rig applications

• Field recording in combination with external cameras

The combination of monitoring and recording allows the device to function as a compact recorder-monitor.

Limits

• SDI limited to 1080p60

• No RAW recording

• External power supply or NP-F batteries required

• Maximum recording quality depending on codec (H.264/H.265)

• No internal ProRes or DNx recording
